Product Dimensions 12.63"h x 6.81"w x 3.87"d
With Balanced Double Surround System (BDSS™) technology, DI 5.5BPS surround speakers deliver the bass output and dynamic range of traditional 8" speakers. Hidden within your walls or ceiling, lifelike sonic performance and broad, even dispersion become even more impressive. While other in-wall speakers fall short on sound quality and stealth, the DI 5.5 BPS sets an impossibly high standard.Read More
White Finish
Powerful sound performance comes through with Bipolar sound dispersion and the latest-gen BDSS™ drivers
Flangeless design, micro-perf grille and flush mounting minimize visibility
Pure aluminum dome tweeters and adjustable high-definition crossover produce pristine highs
Rigid PolyStone™ baskets eliminate unwanted vibrations to prevent ringing and minimize distortion
The pivoting pure aluminum dome tweeter features a uniquely constructed housing, eliminating diffraction distortions typical with traditional speakers for spectacular audio performance.
BDSS™ technology, aim-ready tweeters and a specially-contoured AeroRing™ around the driver distributes natural, well-balanced sound everywhere in the room.
A sophisticated adjustable crossover network with custom, high-precision components produces superior sonic purity for crisp, clean sound.
With a minimal visible surface area, hidden flange architecture and micro-perf grille, the DI 5.5BPS disappears into any environment, without the need for custom sheetrock or spackle work.
General Specs | |
| Product Weight (lbs.) | 8.4 |
| Weight Kilogram | 4.989512 |
| MPN | UEZA |
| Height (cm.) | 32.0802 |
| Depth (cm.) | 9.8298 |
| Width (cm) | 17.2974 |
| Product Weight (kg) | 3.78 |
| Color | Black |
| Impedance | 8 ohms |
| Number of Speakers | 1 |
| Depth (in.) | 3.87 |
| Height (in.) | 12.63 |
| Width (in.) | 6.81 |
Specifications | |
| Speaker Type | In-Ceiling Speaker |
| Sold As | Each |
| colour | White |
| Availability | US |
| Depth | 3.88" (9.86 cm) |
| Weight | 8.4 lbs (3.81 kg) |
| Grille Dimensions | 13.63" (34.62 cm) h x 7.75" (19.69 cm) w |
| Shipping Carton | 6.75" (17.15 cm) h x 15.56" (39.52 cm) w x 9.75" (24.77 cm) d |
| Shipping Weight | 11 lbs (4.99 kg) |
Driver Complement | |
| Pivoting Dome Tweeter - Tweeter | (2) 1" (2.54 cm) d (Round) Pivoting Dome Tweeter - Tweeter |
| BDSS Bass/Mid - Mid/Woofer | (2) 5.25" (13.34 cm) d (Round) BDSS Bass/Mid - Mid/Woofer |
In-Wall Mount | |
| Shape | Rectangle |
| Dimensions | 12.63" (32.08 cm) h x 6.81" (17.3 cm) w |
| Clearnace Required for Mounting Dogs (add to each side of cutout) | 1" (2.54 cm) |
In-Ceiling Mount | |
| Shape | Rectangle |
| Dimensions | 12.63" (32.08 cm) h x 6.81" (17.3 cm) w |
Inputs | |
| Speaker Inputs | (1) Pair of Heavy Duty, Spring Loaded - na |
Audio Quality | |
| Total Frequency Response | 28 Hz to 30 Hz |
| Nominal Impedance | 8 Ohms |
| Max Sensitivity (1 watt @ 1 meter) | 89 dB |
Crossover | |
| Type | A/V Receiver Crossover Settings |
| A/V Receiver Crossover Settings | Small (60 Hz) |
Warranty | |
| Cabinet Warranty | 5 Years |
| Drivers Warranty | 5 Years |
Included Accessories | |
| Wall Mounting Template | 1 |
| Paintable Magnetic Grille | 1 |
