Product Dimensions 4.75"h x 30"w x 20"d
With a compact 4 3/4" height, Bellagio is an ideal choice where under-cabinet space is limited. An upgraded 4-speed, 400 CFM internal blower provides sufficient ventilation power, equipped with dishwasher-safe, anodized aluminum mesh filters and multiple backlight color touch controls illuminate in elegant white, green, blue or red.Read More
Available in 30” or 36” width, Bellagio is designed for standard ducted installation, and can also be installed as a recirculating system using the Recirculating Kit, available as an accessory.
Illuminate your culinary journey with LED brilliance. An expected lifetime of over 20,000 hours represents the most remarkable advantage of LED light bulbs.
Elevate your kitchen with superior filtration. Aluminum mesh filters are steps above competition, featuring triple-layered, anodized aluminum that is woven into a highly dense mesh.
Customize CFM with ease. Enables users to reduce directly the maximum blower CFM to meet local code requirements.
General Specs | |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Range Hood Type | Under Cabinet |
| Ventilation Type | Convertible (Both) |
| Ventilation Direction | Vertical/Horizontal |
| Vent Location | Custom |
| Grease Filter Type | Aluminum Mesh |
| Duct Size (in.) | 10" x 3.25" Rectangular or 7" Round |
| Bulb Type | LED |
| Sones Rating | 0.9 - 5 |
| Noise Level (Sones) | Standard - (High), Moderate - (Medium), Quiet - (Low) |
| Maximum CFM | 400 |
| Range Hood Features | Light |
| Smart Compatible | No |
| Filter Indicator Light | No |
| Fan Speed Options | 4 |
| Outdoor Approved | No |
| Appliance Fit Width (in.) | 30 |
| Appliance Fit Width (cm) | 77 |
| Width (in.) | 30 |
| Width (cm) | 76.2 |
| Height (in.) | 4.75 |
| Height (cm) | 12.07 |
| Depth (in.) | 20 |
| Depth (cm) | 50.8 |
| Product Weight (lbs.) | 22.05 |
| Product Weight (kg) | 10 |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Collection | Bellagio |
| Series | Comfort Series |
| Manufacturer Warranty | 2 Year Parts & Labor |
| Voltage | 120 |
| Frequency | 60 |
