General Specs |
| Projector Brightness | 2400 |
| Lamp Life | 5000 |
| Vertical Keystone Correction | Yes |
| Width (in.) | 20.5 |
| Width (cm) | 52.07 |
| Depth (in.) | 17.7 |
| Depth (cm) | 44.96 |
| Height (in.) | 7.6 |
| Height (cm) | 19.30 |
| Product Weight (lbs.) | 24.3 |
| Product Weight (kg) | 11.02 |
| MPN | V11H932120MB |
Specifications |
| Projection System | Epson 3LCD, 3-Chip Design |
| Projection Method | Front / Rear / Ceiling mount |
| Driving Method | Epson Poly-silicon TFT Active Matrix, 0.74-inch wide panel |
| colour Brightness- colour Light Output | 2400 lumens |
| White Brightness- White Light Output | 2400 lumens |
| Aspect Ratio | 16:9 widescreen (4:3 resize, 16:10 resize);
Compatible with 4:3 with Normal, Full or Zoom Modes |
| Native Resolution | 4K Enhancement1 (1920 x 1080 x 2); Max. Resolution: 4096 x 2160 |
| Lamp Type | 250 W UHE |
| Lamp Life | Up to 5,000 hours (ECO Mode); up to 4,000 hours (Medium Mode); up to 3,500 hours (High Mode) |
| Throw Ratio Range | 1.35 – 2.84 |
| Keystone Correction | Vertical: ±30 degrees (Manual) |
| Contrast Ratio | Up to 200,000:1 |
| colour Processing | Full 10-bit (partial 12-bit) |
| colour Reproduction | Full-colour (up to 1.07 billion colours) |
General |
| Weight | 24.3 lb |
| Security | Kensington Security Lock Port |
| Case colour | Black |
Projections Lens |
| Type | Powered focus/optical zoom/lens position |
| F-Number | 2.0 – 3.0 |
| Focal Length | 22.5 mm – 46.7 mm |
| Zoom Ratio | 1.0 – 2.1 |
| Lens Shift | Vertical: ±96.3 / Horizontal: ±47.1 |
| Lens Cover | Powered, Slide Lens Shutter |
Other Home Projector |
| Cinema Filter | Automatically adjusts to colour mode; On: Cinema, Digital Cinema; Off: Natural, Black & White Cinema, Bright Cinema, Dynamic, 3D Dynamic, 3D Cinema |
| Auto Iris | Automatically adjusts to video source: Off/On: High-speed or Normal, 2D and 3D mode |
| Super Resolution | 2D and 3D |
| Frame Interpolation | 1080p, 24 Hz |
| Terminal Inputs | HDMI® x 1 (HDCP 2.2); HDMI x 1 (HDCP 1.4); USB Type A (for optical HDMI cable 300 mA max. power supply only) x1; USB (for wireless and firmware) x1; Mini USB x 1 (service only); LAN x 1 (RJ45); Computer/D-sub 15 pin x 1; RS-232c x 1 |
| Terminal Outputs | Trigger out 12 V DC, 200 mA maximum |
Parental Controls |
| Power Button Lock | Power Button Lock hinders projector from being turned on without parental supervision |
Projector Details |
| Display Performance | 4K/UHD compatible, HDR, 3 dimensional DCI-P3 colour gamut3, 4K Enhancement1, 1080p; HD, 2D, 3D, 2D-to-3D conversion, Picture-in-Picture (2D only) Frame Interpolation (1080p, 24 Hz) (2D and 3D); Output Configuration: (1920 x 1080 x 2) x 3 LCD chips |
| colour Modes | 2D: Dynamic, Bright Cinema, Natural, Cinema, Digital Cinema, Black & White Cinema; 3D: Dynamic, Cinema |
| Fan Noise | 20 dB – 31 dB |
Projector Dimensions |
| Including Feet | 20.5" x 17.7" x 7.6" (W x D x H) |
Remote Control |
| Features | Front and rear directional |
| Operating Distance | 32 feet (10 meters) |
| Operating Angle | Front: Right/Left: ± 30 degrees, Upper/Lower: ± 30 degrees; Rear: Right/Left: ± 30 degrees, Upper/Lower: + 10 – + 70 degrees |
Power |
| Power Power Supply Voltage | 100 – 240 VAC ± 10%, 50/60 Hz |
| Power Consumption | ECO Mode: 283 W; Normal Mode: 373 W |
