Balanced Neodymim Tweeter provides detailed high range and smooth mid range. Installable vehicle types are greatly increased thanks to its shorter height. Grill’s opening ratio is 30% wider than the conventional model, enabling increased durability and clear sound.Read More
It provides detailed high range and smooth mid range.
Installable vehicle types are greatly increased thanks to its shorter height.
Grill’s opening ratio is 30% wider than the conventional model, enabling increased durability and clear sound.
Robust and lightweight carbon mica material provides highly responsive, clear and undistorted reproduction.
Rubber Coated Cloth with increased mobility enables high efficiency and improved follow-up to audio signals.
Newly developed small cover significantly reduces areas that interfere with the woofer cone. High-quality sound is assured.
General Specs | |
| RMS Power Handling (Watts) | 70 |
| Peak Power Rating (Watts) | 500 |
| Impedance | 4 Ohms |
| Water Resistant | No |
| Mounting Hardware Included | No |
| Color | Black |
| Color-Finish Name | Black |
| Product Weight (lbs.) | 2.4 |
| Product Weight (kg) | 1.09 |
| Collection | drvn DR Series |
Woofer | |
| Size | 15 x 23 cm (6'' x 9'') |
| Diaphragm | Carbon Mica Cone |
| Surround | Hybrid Surround (Rubber & Cloth) |
| Magnet | Ferrite |
Midrange | |
| Size | 6.6 cm (2-5/8'') |
| Type | Cone |
| Diaphragm | Poly-Ether Imide |
| Magnet | Ferrite |
Tweeter | |
| Size | 1.5 cm (19/32'') |
| Type | Dome |
| Diaphragm | Poly-Ether Imid |
General | |
| Frequency Response | 58 - 21,000Hz |
| Sound Pressure Level | 88dB |
| Weight (w.Grille) | 1.07kg (2.4lbs) |
| Weight (w/o Grille) | 0.99kg (2.2lbs) |
| Magnet Mass | 285g (10oz) |
| Mounting Depth | 79 mm (3-1/8") |
