General Specs |
| Color | Custom |
| Color/Finish Name | Panel Ready |
| Range Hood Type | Wall Mounted |
| Ventilation Type | Convertible (Both) |
| Vent Location | Top |
| Duct Size (in.) | 6" Round |
| Bulb Type | Halogen |
| Range Hood Features | Light, Removable Grease Filter |
| Fan Speed Options | 3 |
| Appliance Fit Width (in.) | 30 |
| Appliance Fit Width (cm) | 76 |
| Width (in.) | 30 |
| Width (cm) | 76.2 |
| Height (in.) | 17.75 |
| Height (cm) | 45.09 |
| Depth (in.) | 10.88 |
| Depth (cm) | 27.64 |
| Height Above Cooktop | 24.13 - 26 |
| Height Above Cooktop Centimeter | 61.29 - 66.04 |
| Product Weight (lbs.) | 38 |
| Product Weight (kg) | 17.24 |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| MPN | 07200050 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Voltage | 120 |
| Amp | 15 |
| Frequency | 60 |
Construction Type |
| Slot-in ventilation hood | Yes |
| Colour | Stainless steel |
Operating Modes |
| Type of air guide | Convertible |
User Convenience |
| Electronic controls | Yes |
| Programmable booster level switch-off | Yes |
Filter System |
| Number of dishwasher-safe stainless steel grease filters (10-ply) | 2 |
| Number of dishwasher-safe metal grease filters | 2 |
Lighting |
| Number x W | 2 x 20 W |
| Light intensity in Lx | 630 lx |
Technical Data |
| Minimum height above electric cooktops in. (mm) | 24 1/8 (610) |
| Minimum height above gas cooktops (max. 12.6 kW total output, burner ≤ 4.5 kW) in. (mm) | 26 (660) |
| Dual-action fan | Yes |
| AC motor | Yes |
| Length of power cable in m | 3 (1.2) |
| Number of phases | 1 |
Accessories Supplied |
| Installation template | Yes |
| Non-return flap | Yes |
