General Specs |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Fuel Type | Natural Gas |
| Burner Type | Sealed |
| Number of Elements/Burners | 5 |
| Cooktop Surface Style | Burner Grate |
| Ignition Type | Automatic Electronic |
| Grate Material | Cast Iron |
| Cooktop Features | Continuous Grate, Dishwasher Safe Grates, Automatic Shutoff, Dual Element |
| Downdraft Ventilation | No |
| Appliance Fit Width (in.) | 36 |
| Appliance Fit Width (cm) | 90 |
| Width (in.) | 35.5 |
| Width (cm) | 90.17 |
| Depth (in.) | 20.5 |
| Depth (cm) | 52.07 |
| Height (in.) | 3.6 |
| Product Weight (lbs.) | 41 |
| Product Weight (kg) | 18.6 |
| Cut Out Width (in.) | 33.88 |
| Cut Out Width (cm) | 86.06 |
| Cut Out Depth (in.) | 19 |
| Cut Out Depth (cm) | 48.26 |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Manufacturer Warranty | 1 Year Parts & Labor |
| MPN | 07307360 |
| Voltage | 120 |
| Frequency | 60 |
Technical Data |
| Length of power cable in inches (m) | 3 (1.2) |
1st Cooking Zone |
| Maximum rating in W | 3800 |
| Type | Single wok burner - Front left |
2nd Cooking Zone |
| Maximum rating in W | 1000 |
| Type | Economy burner - Rear left |
3rd Cooking Zone |
| Maximum rating in W | 2600 |
| Type | High-speed burner - Centred |
4th Cooking Zone |
| Maximum rating in W | 1750 |
| Type | Standard burner - Rear right |
5th Cooking Zone |
| Maximum rating in W | 1750 |
| Type | Standard burner - Front right |
