Monitor Audio CS140 In-Ceiling Square Speaker
At a Glance
The CS140 in-ceiling model features a proprietary 4-inch MMP II cone and a pivoting version of our acclaimed C-CAM Gold Dome tweeter.Read More
Call for Best Price
The CS140 in-ceiling model features a proprietary 4-inch MMP II cone and a pivoting version of our acclaimed C-CAM Gold Dome tweeter.Read More
Engineered for excellent detail resolution and complete with either round or square grilles
CS140 will deliver great sound with super-discreet aesthetics.
Square Grille
This product is now available to use with home theatre design software, The CEDIA Designer.
General Specs | |
| Color | Black, Orange |
| Speaker Type | In-Ceiling Speakers |
| RMS Power Handling (Watts) | 50 |
| Frequency Response | 75 Hz – 30 kHz |
| Impedance | 6 ohms |
| Sensitivity | 85 |
| Number of Speakers | 1 |
| Product Weight (lbs.) | 2.63 |
| Manufacturer Warranty | Limited Lifetime |
Additional Specifications | |
| Frequency Response | 75 Hz – 30 kHz |
| Nominal Impedance | 6 ohms |
| Sensitivity (1W@1M) | 85 dB |
| Maximum SPL | 102.8 dBA |
| Power Handling (RMS) | 50 W |
| Recommended Amplifier Requirements | 10 – 50 W |
| Drive Unit Complement | 1 x 4" MMP II cone bass driver., 1 x 1" (25 mm) C-CAM pivoting Gold Dome tweeter |
| Acoustic Configuration | 2-way |
| Overall Dimensions (Including Grille (H x W)) | Square: 176.7 x 176.7 mm (6 15/16 x 6 15/16") |
| Mounting Depth | 98.6 mm (3 7/8") |
| Cut-Out Hole Diameter | 149 mm (5 7/8") |
| Fixing Type | 3 position Tri-Grip dog fixings |
| Connection | Gold plated ‘push’ type terminals |
| Grille Attachment | Magnetic |
| Construction Material | Mineral filled ABS, RoHS compliant |
| Weight | 1.18 kg (2 lb 10 oz) |
| Pre-Construction Bracket | CB4 Pre-Construction Bracket (Pink) |
| Back Box | CCBOX-R |
