Product Dimensions 14.63"h x 8.88"w x 12.63"d
All the wonder of Platinum II’s crystal clear tonal precision is concentrated by this beautiful little two-way speaker comprising a single 6.5" RDT II mid-bass driver and MPD tweeter.Read More
Easy to place in-room the PL100 II will nevertheless belie its compact dimensions with a wide open soundstage punctuated by breath-taking dynamics and imaging so stable you can almost touch it. A bespoke floor stand (available separately) will position the PL100 II at the perfect listening height.
6.5" RDT II bass / mid driver
MPD (Micro Pleated Diaphragm) high frequency transducer designed specifically for Platinum II
Single rear HiVe II port
Patented 'DCF' (Dynamic Coupling Filter) mechanism for more natural sound
Bespoke speaker terminals and footings
Underhung, edge-wound voice coils: greater driver efficiency and lifelike dynamics, less distortion
Bolt through drivers: clearer sound and cleaner aesthetics
Anti-Resonance Composite (ARC) mid-range housings and baffle components: reduced cabinet vibration, purer sound quality
Hand-upholstered front baffle: the very highest quality Inglestone leather supplied by Andrew Muirhead
Individual driver grilles
Finish options: Santos Rosewood or Ebony natural wood veneers with clear gloss piano lacquer, or Piano black gloss lacquer
Optional dedicated floor stand available
This product is now available to use with home theatre design software, The CEDIA Designer.
General Specs | |
| Color | Black |
| Color/Finish Name | Ebony Wood |
| RMS Power Handling (Watts) | 120 |
| Impedance | 6 ohms |
| Number of Speakers | 2 |
| Width (in.) | 8.88 |
| Depth (in.) | 12.63 |
| Height (in.) | 14.63 |
| Product Weight (lbs.) | 32.88 |
| Manufacturer Warranty | 5 Year |
Additional Specifications | |
| System Format | 2 Way - 2 Driver |
| Frequency Response (-6 dB - IEC 268-13) | 40 Hz — 100 kHz |
| Sensitivity (1W@1M) | 88 dB |
| Maximum SPL | 111.8 dBA (pair) |
| Nominal Impedance | 6 ohms (4.5Ω min. @ 160 Hz) |
| Power Handling (RMS) | 120 W |
| Recommended Amplifier Requirements | 60 — 120 W |
| Cabinet Design | Single rear HiVe II port |
| Drive Unit Complement | 1 x 6 1/2" RDT II bass / mid driver, 1 x MPD high frequency transducer |
| Crossover Frequency | 3.0 kHz |
| External Dimensions (Including Feet and Spikes (H x W x D)) | 372 x 225 x 325.54 mm (14 5/8 x 8 7/8 x 12 5/8") |
| Weight (each) | 14.94 kg (32 lb 14 oz) |
