Product Dimensions 12.13"h x 11.44"w x 12"d
The Radius 380’s twin side-firing 8" C-CAM drivers - one active and one passive ABR - work in tandem with a powerful 140 W cool-running Class D amplifier (double the power of its predecessor). The drivers have no grilles but are colour-coded to coordinate with cabinet finish. A 12 V trigger syncs the 380 with other AV components when the system is activated.Read More
18 mm MDF cabinet construction with internal bracing
Cool-running 140 W Class D amplifier with switch mode power supply (SMPSU)
Twin side-firing 8" C-CAM drivers - one active and one passive ABR
Low pass filter switch – for LFE or Stereo input selection
Power switch with ON – Auto- Off/ trigger settings
Stereo/ LFE RCA inputs
3 x Pre-set EQ settings – Music/Movie/Impact
This product is now available to use with home theatre design software, The CEDIA Designer.
General Specs | |
| Color | Brown |
| Color/Finish Name | Walnut |
| RMS Power Handling (Watts) | 200 |
| Width (in.) | 11.44 |
| Depth (in.) | 12 |
| Height (in.) | 12.13 |
| Product Weight (lbs.) | 22.38 |
| Manufacturer Warranty | 5 Year |
Additional Specifications | |
| System Format | Active sub-woofer system – Auxiliary (ABR) loading. 18 mm MDF cabinet |
| Lower Frequency Limit | 30 Hz (- 6 dB) |
| Upper Frequency Limit | Variable 40 – 120 Hz @ 24 dB/Octave |
| Amplifier Output | 140 Watts @ 1% THD+N |
| Amplifier Classification | Class D amplifier with Switch mode power supply (SMPSU) |
| Bass EQ Profiles | Music / Movie / Impact |
| Phase Control | 0 & 180 degrees |
| Auto Sensing | Line Level >3.5mV |
| Input Level Requirements | Standby after approximately 15 minutes if no signal sensed |
| Drive Unit Complement | 1 x 8” (200 mm) C-CAM long throw driver 1 x 8” (200 mm) ABR |
| Input Impedance | > 20 ohms |
| Mains Input Voltage | AC 110 - 120 V ~ 50/60Hz; AC 220 - 240 V ~ 50/60Hz (Factory Region Preset) |
| Dimensions (Including Amp and Feet (H x W x D)) | 308 x 290 x 305 mm (12 1/8 x 11 7/16 x 12") |
| Connection | Stereo RCA in, LFE in, 12v Trigger in (3.5 mm mono mini-jack) |
| Trigger Input | 5 - 12v via 3.5 mm mono mini-jack socket |
| Power Consumption | 200 Watts / 0.5 Watts in Standby (ErP approved) |
| Weight (unpacked) | 10.16 kg (22 lb 6 oz) |
