An 8-inch C-CAM bass driver and a more highly specified version of the C-CAM Gold Dome tweeter offer an extended high-frequency response to 30 kHz, as well as higher output and power handling capacity.Read More
Optimum imaging and set-up
Pivoting tweeter
High frequency (+3 dB / 0 dB / -3 dB) level adjustment
Boundary compensation (on / off) controls
This product is now available to use with home theatre design software, The CEDIA Designer.
General Specs | |
| Color | Black |
| Speaker Type | In-Wall Speakers |
| RMS Power Handling (Watts) | 120 |
| Frequency Response | 45 Hz – 30 KHz |
| Impedance | 6 ohms |
| Sensitivity | 90 |
| Number of Speakers | 1 |
| Product Weight (lbs.) | 6.8 |
| Manufacturer Warranty | Limited Lifetime |
Additional Specification | |
| Frequency Response | 45 Hz – 30 KHz |
| Nominal Impedance | 6 ohms |
| Sensitivity (1W@1M) | 90 dB |
| Maximum SPL | 111.6 dBA |
| Power Handling (RMS) | 120 W |
| Recommended Amplifier Requirements | 30 – 120 W |
| Drive Unit Complement | 1 x 8" C-CAM cone bass driver, 1 x 1" C-CAM Pivoting Gold Dome tweeter |
| Adjustment Controls | HF Level Switch (+3 dB / 0 dB / -3 dB), Boundary Compensation Switch |
| Overall Diameter (Including Grille) | 441 x 288 mm (17 3/8 x 11 5/16") |
| Overall Depth (Including Grille) | 104 mm (4 1/8") |
| Mounting Depth | 100 mm (3 15/16") |
| Cut-Out Hole Diameter | 387 x 234 mm (15 1/4 x 9 3/16") |
| Fixing Type | 6 position Tri-Grip dog fixings |
| Construction Material | Mineral filled ABS, RoHS compliant |
| Weight | 3.1 kg (6.8 lb) |
| Pre-Construction Bracket | WB8 Pre-Construction Bracket (Green) |
| Back Box | WCBOX-L |
