Porter & Charles special gas burner design produces a clean and perfect flame. They come in a range of sizes and BTU’s for cooking flexibility and precision. With the UltraFlat stainless steel design, these cooktops will integrate beautifully into any kitchen design.Read More
5 high quality gas burners
Continuous cast iron support grates
Cast iron wok support ring
UltraFlush stainless steel design
Ergonomically placed control knobs
Electronic ignition
Flame failure safety system
Shallow depth allows for easy install over drawers or an oven
General Specs | |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Fuel Type | Natural Gas |
| Number of Elements/Burners | 5 |
| Cooktop Surface Style | Burner Grate |
| Ignition Type | Automatic Electronic |
| Grate Material | Cast Iron |
| Cooktop Features | Continuous Grate |
| Downdraft Ventilation | No |
| Appliance Fit Width (in.) | 30 |
| Appliance Fit Width (cm) | 75 |
| Width (in.) | 29.38 |
| Width (cm) | 74.63 |
| Depth (in.) | 20.06 |
| Depth (cm) | 50.95 |
| Cut Out Width (in.) | 28.31 |
| Cut Out Width (cm) | 71.91 |
| Cut Out Depth (in.) | 19 |
| Cut Out Depth (cm) | 48.26 |
| Manufacturer Warranty | 2 Year Parts & Labor |
| Voltage | 115 |
| Frequency | 60 |
| Amp | 15 |
Cooktop Performance | |
| Double Ring Wok Burner | 17,500 BTU |
| Rapid Burner | 11,500 BTU |
| Semi-Rapid Burners (2) | 8,000 BTU |
| True Simmer Burner | 5,000 BTU down to 600 BTU |
Details | |
| Power Supply | 5 ft. electrical cord and plug included |
| Gas Connection and Fittings | 1/2" gas inlet and outlet fittings |
