General Specs |
| Amplifier Channels | 8 |
| Amplifier Class | Class D |
| Amplifier Output (Watts) | 125 |
| Frequency Response | 15 |
| Impedance | 8 ohms |
| Analog Audio(RCA) Input | 2 |
| Analog Audio(RCA) Output | 1 |
| Headset Jack | No |
| Wifi Capable | Yes |
| Bluetooth Capable | No |
| Smart Compatible | Yes |
| Streaming Capable | Yes |
| Featured Streaming Services | Apple Airplay 2, Spotify |
| Outdoor Approved | No |
| Color | Black |
| Color/Finish Name | Black |
| Width (in.) | 17.2 |
| Width (cm) | 43.69 |
| Depth (in.) | 10.44 |
| Depth (cm) | 26.52 |
| Height (in.) | 2.52 |
| Height (cm) | 6.4 |
| Product Weight (lbs.) | 11.16 |
| Product Weight (kg) | 5.06 |
| Voltage | 100-240 |
| Amp | 10 |
Audio |
| Speaker Outputs | 8 amplified outputs each independently configurable for stereo or mono |
| Power | 125 W per channel @ 8Ω (all channels driven) |
| Minimum Impedance | 2.67Ω with Sonos Architectural speakers |
| Damping Factor | >400 (ref. 8 ohms, 20 Hz to 1 kHz) |
| Amplifier Technology | Class D with GaN and PFFB |
| Total Harmonic Distortion | 0.005% at 2.83Vrms-15Vrms |
| Frequency Response | ±0.5 dB, 15 Hz - 20 kHz |
| Channel Separation (Crosstalk) | -100dB at 1 kHz 2.83Vrms -80dB at 10 kHz 2.83Vrms |
| Signal-to-Noise Ratio | 114dB ref 125W into 8-Ohm |
| ProTune | 10-band parametric EQ with ±15dB gain, Q, and frequency control. Option for high-shelf, low-shelf, and bell filter types. Gain trim: -15 - +5 dB Delay: 0 - 50ms Highpass: 15-100Hz All available on per-channel basis |
| Optimize Sonos Speakers | When selected in the Sonos app, Optimize Sonos Speakers allows Amp Multi to recognize Sonos Architectural speakers, then applies custom tuning and DSP to provide more robust sound with a more even frequency response, optimizing system performance and ensuring stable operation. |
Details + Dimensions |
| Dimensions (Single Unit) | Height: 2.52 in (64.5 mm) Width: 17.2 in (436.8 mm) Depth: 10.44 in (265.2 mm) |
| Dimensions (with 2U Rack Mount) | Height: 3.47 in (82.3 mm) Width: 19.01 in (483 mm) Depth: 10.44 in (265.2 mm) |
| Weight | 11.16 lbs (5.06 kg) |
| Colours | Black |
| Finish | Matte |
| LEDs | Front: Device status Rear: Device status, output status (x8), RJ45 status light |
Power + Connectivity |
| Power Consumption | 5.4 W (idle) 180 W (all channels driven at 1/8 output power, 8 Ohms) |
| Power | Auto-switching 100-240V 50/60Hz 10A AC universal input |
| Wired Networking Interface | 100BaseTX, Ethernet RJ45 |
| Wireless Networking Interface | Compatible with WiFi 6. Connect to Wi-Fi with any 802.11a/b/g/n/ac/ax 2.4 GHz/5 GHz broadcast-capable router. |
| Analogue Audio Input | 2 x RCA inputs -10dB (stereo into one zone) |
| USB-C Analogue Audio Input | 44.1 kHz / 16 bit (stereo into any zone) Requires Sonos Line-In Adapter |
| Subwoofer Connections | 1 x RCA output -10dB (configurable to output from one zone), and 1x Sonos Sub per zone |
| Direct Streaming Formats | Apple AirPlay 2, Spotify Direct Control, and more. |
| CPU | Quad Core 4xA55 1.9GHz |
Box Contents |
| Power Cable | Length: 6 ft (2 m) |
| Sonos Banana Plugs | Set of eight (8) |
| Documentation | Quickstart Guide and legal/warranty information |
Requirements |
| Speakers | Passive speakers required for audio output |
| Internet Connection | Ethernet connection or WiFi Ethernet needs Category 5 (CAT5) cable or higher |
| Power Source | Nearby electrical outlet |
| Sonos app | The latest generation of the Sonos app running on a compatible device |
