Product Dimensions 36.66"h x 47.88"w x 26.75"d
High performance burners provide fast boil times and a gentle simmer. 20,000 BTU – 8,500 BTU high burner ratings. Stainless steel burner pan. Electronic single point spark ignition/re-ignition on all burners. Porcelain coated cast iron burner grates. Optional surface configurations.Read More
High performance burners provide fast boil times and a gentle simmer.
20,000 BTU – 8,500 BTU high burner ratings.
Stainless steel burner pan.
Electronic single point spark ignition/re-ignition on all burners.
Porcelain coated cast iron burner grates.
Optional surface configurations.
Machined steel griddle/simmer plate (with grease collection drawer).
Cast iron French top.
Induction elements.
Polished chrome die cast knobs.
Large Left Oven – 3.8 cu ft. electric oven.
25 3/4”W. x 13”H. x 19 5/8” D.
Eight cooking functions – Bake, Convection Bake, Tru Convection, Low Broil, High Broil, Convection Broil, Defrost, Proof.
Stainless steel oven cavity.
Six rack positions with two oven racks including one TruGlide™ Rack.
Two oven lights.
Right Convection Bake Oven – 2.4 cu ft. oven.
11 5/8”W. x 18 1/4”H. x 19 5/8”D.
Side swing oven door.
One oven rack.
Storage drawer for baking pans with soft-close glides.
General Specs | |
| Color | Black |
| Color/Finish Name | Cast Black |
| Door Color | Cast Black |
| Handle Color | Polished Chrome |
| Trim Color | Polished Chrome |
| Total Capacity (cu. ft.) | 6.2 |
| Total Upper Oven Capacity (cu. ft.) | 2.4 |
| Total Lower Oven Capacity (cu. ft.) | 3.8 |
| Number of Oven(s) | Single |
| Fuel Type | Dual Fuel (NG) |
| Door Panel Type | Solid |
| Burner Type | Sealed |
| Range Type | Pro-Style |
| Number of Elements/Burners | 6 |
| Cooktop Surface Style | Burner Grate |
| Cooktop Surface | Porcelain Coated |
| Grate Material | Porcelain-Enameled Cast Iron |
| Oven Cleaning Method | Manual Clean |
| Total Number Of Oven Racks | 3 |
| Total Number Of Rack Positions | 5 |
| Oven Features | Adjustable Leg Height, Gliding/Roll Out Rack, Oven Light, Proofing Mode, Broiler in Oven, Defrost |
| Cooktop Features | Continuous Grate, Griddle Included, LP Convertible, Removable Grates, Simmer Element |
| Air Fry | No |
| Induction Cooking | No |
| Convection Cooking | Yes |
| Smart Compatible | No |
| Outdoor Approved | No |
| Drawer Type | Storage |
| Appliance Fit Width (in.) | 48 |
| Appliance Fit Width (cm) | 122 |
| Width (in.) | 47.88 |
| Width (cm) | 121.6 |
| Height (in.) | 36.66 |
| Height (cm) | 93 |
| Depth (in.) | 26.75 |
| Depth (cm) | 77.2 |
| Depth w/Door Open 90 Degrees (in.) | 40 |
| Depth With Door Open 90 Degrees (cm) | 101.6 |
| Cut Out Width (cm) | 121.9 |
| Product Weight (lbs.) | 510 |
| Product Weight (kg) | 230 |
| Weight Kilogram | 227.8 |
| Manufacturer Warranty | 2 Year Parts & Labor |
| Commercial Use Approved | No |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Collection | Tuscany |
| Voltage | 208 - 240 |
| Amp | 28.5 |
